Electroless Nickel Plating

Services

Electroless Nickel Plating

Electroless Nickel Plating is the deposition of a nickel-phophorous alloy onto a metal substrate without the use of an electrical current. The electroless nickel plating process utilizes an autocatalytic chemical reaction to deposit a reliable, repeatable coating of uniform thickness. This uniformity of deposit can, in some cases, eliminate the need for post-plate grinding. Electroless nickel demonstrates excellent corrosion protection, with similar lubricity properties to plated chromium. Electroless nickel effectively coats parts with sharp edges, deep recesses, seams, threads, and complex geometries.

We offers varying alloys of nickel and phosphorous, including:

  • High Phosphorus (10% to 13%): superior corrosion protection; most resistant to acidic environments; greater than 65 Rc hardness with post-plate thermal treatment.
  • Medium Phosphorus (5% to 9%): best appearance.
  • Low Phosphorus (<5%): highest as-plated surface hardness (up to 60 Rc); most resistant to alkaline environments; best solderabilaty.

Electroless nickel can also be rendered non-magnetic, making it the optimal choice for electromagnetic shielding. Electroless nickel can be applied over a variety of substrates including stainless steel, aluminum, copper, brass and many proprietary alloys.
